TP-Link Omada 28-Port Gigabit Smart Switch with 24-Port PoE+

Product image of TP-LINK TL-SG2428P
  • Product image of TP-LINK TL-SG2428P 1

Images are illustrative. The product shown may differ from the one offered or include components not part of the product set.

VendorTP-LINK
Product codeTL-SG2428P
Warranty 5 years
Price€358.60
Price (excl. VAT)€289.19
Ships in 4-7 bd
Quantity5+ pcs
Buy now

Ships quicker

TP-LINK | JetStream 28-Port Gigabit Smart Switch | TL-SG2428P | Web Managed | Rackmountable | SFP ports quantity 4 | PoE+ ports quantity 24 | Power supply type Single
Product code: SG2428P
4 pcs
1-3 bd
€350.80
TP-Link JetStream TL-SG2428P Switch 24-porte Gigabit PoE+
Product code: TL-SG2428P
1 pcs
4-6 bd
€314.10
Product description
Product inquiry
Product colour:
Black
Form factor:
1U
Rack mounting:
Yes
Number of fans:
2 fan(s)
AC input frequency:
50/60 Hz
Power supply included:
Yes
Power consumption (max):
301.1 W
Power source:
AC
AC input voltage:
100 - 240 V
Access Control List (ACL):
Yes
Queue scheduling algorithms:
SP, WRR+SP, Weighted Round Robin (WRR)
SSH/SSL support:
Yes
Authentication type:
RADIUS
IGMP snooping:
Yes
DHCP features:
DHCP server, DHCPv6 client, DHCP client, DHCP relay, DHCP snooping
BPDU filtering/protection:
Yes
IP-MAC-Port binding:
Yes
Security algorithms:
SNMPv3, SSH, SSH-2, SNMPv2, HTTPS, SNMP, SSL/TLS
Heat dissipation:
1052.94 BTU/h
Storage temperature (T-T):
-40 - 70 °C
Operating relative humidity (H-H):
10 - 90%
Operating temperature (T-T):
0 - 50 °C
Storage relative humidity (H-H):
5 - 90%
ARP inspection:
Yes
Switch layer:
L2/L2+
System event log:
Yes
Switch type:
Managed
MIB support:
Y
Web-based management:
Yes
Quality of Service (QoS) support:
Yes
Height:
44 mm
Width:
440 mm
Depth:
220 mm
Virtual LAN features:
MAC address-based VLAN, Voice VLAN, Protocol-based VLAN
Cable types supported:
Cat4, Cat5, Cat5e, Cat3
Port mirroring:
Yes
Rate limiting:
Yes
Number of VLANs:
4000
Flow control support:
Yes
Broadcast storm control:
Yes
Link aggregation:
Yes
Spanning tree protocol:
Yes
Networking standards:
IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1D, IEEE 802.3z, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3x, IEEE 802.1x, IEEE 802.1w, IEEE 802.3at, IEEE 802.3ad, IEEE 802.1s
10G support:
No
Copper ethernet cabling technology:
10BASE-T, 1000BASE-T
VLAN support:
Yes
Firmware upgradeable:
Yes
Rack mount kit:
Yes
User guide:
Yes
Cables included:
AC
Management protocols:
SNMPv1/v2c/v3, SNTP
Gigabit Ethernet (copper) ports quantity:
24
SFP module slots quantity:
4
Basic switching RJ-45 Ethernet ports quantity:
24
Basic switching RJ-45 Ethernet ports type:
Gigabit Ethernet (10/100/1000)
Number of queues:
8
MAC address table:
8000 entries
Packet buffer memory:
4.1 MB
Forwarding rate:
41.66 Mpps
Jumbo frames:
9000
Jumbo frames support:
Yes
Switching capacity:
56 Gbit/s
Power over Ethernet plus (PoE+) ports quantity:
24
Total Power over Ethernet (PoE) budget:
250 W
Power over Ethernet (PoE) power per port:
30 W
Power over Ethernet (PoE):
Yes
Multicast support:
Yes
Warnings:
Ensure the unit is adequately ventilated during operation., The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations., Do not open the case or try to repair it yourself.
Fiber ethernet cabling technology:
1000BASE-X
