GIGABYTE Z890 Aorus Xtreme AI Top Mainboard, Sockel LGA 1851, Intel Z890, eATX, DDR5
<
>
<
>
Pildid on illustratiivsed. Nendel kujutatud toode võib erineda pakutavast või sisaldada tootekomplekti mittekuuluvaid osiseid.
VendorGigabyte
Product codeZ890 A XTREME AI TOP
Price€1,876.31
Price (excl. VAT)€1,513.15
Delivery
Out ouf stock
Processor manufacturer:
Intel
Processor socket:
LGA 1851 (Socket V1)
Compatible processor series:
Intel Core Ultra (Series 2)
Supported processor sockets:
LGA 1851
Maximum internal memory supported by processor:
256 GB
Supported memory types:
DDR5-SDRAM
Number of memory slots:
4
Maximum internal memory:
256 GB
Memory slots type:
DIMM
Memory channels:
Dual-channel
ECC сompatibility:
ECC & Non-ECC
Supported memory clock speeds:
5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,7900,7950,8000,8200,8266,8400,8600,9500 MHz
Supported memory clock speed (max):
9500 MHz
Unbuffered memory:
Yes
Maximum internal memory per slot:
64 GB
Supported storage drive interfaces:
M.2, SATA III
Supported storage drive types:
HDD & SSD
Number of HDDs supported:
4
Number of storage drives supported:
8
RAID support:
Yes
RAID levels:
0, 1, 5, 10
Parallel processing technology support:
Not supported
Maximum resolution:
7680 x 4320 pixels
HDCP:
Yes
DirectX version:
12.0
USB 2.0 connectors:
2
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
1
Number of SATA III connectors:
4
USB 3.2 Gen 2x2 connectors:
2
Front panel connector:
Yes
ATX Power connector (24-pin):
Yes
CPU fan connector:
Yes
Number of CPU fan connectors:
2
Number of chassis fan connectors:
3
EPS power connector (8-pin):
Yes
Number of EPS power connectors (8-pin):
2
Thunderbolt headers:
1
Number of water pump connectors:
2
Number of temperature sensor headers:
2
Number of noise detection headers:
1
RGB LED pin header:
Yes
Number of RGB LED pin headers:
4
USB 2.0 ports quantity:
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
10
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
0
Ethernet LAN (RJ-45) ports:
2
VGA (D-Sub) ports quantity:
0
HDMI ports quantity:
0
DVI-D ports quantity:
0
Headphone outputs:
1
Microphone in:
Yes
S/PDIF out port:
Yes
Thunderbolt ports quantity:
2
WiFi-AP antenna jack:
2
Wi-Fi:
Yes
Ethernet LAN:
Yes
Ethernet interface type:
10 Gigabit Ethernet
LAN controller:
Marvell AQtion AQC113C
Top Wi-Fi standard:
Wi-Fi 7 (802.11be)
Wi-Fi standards:
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
WLAN controller model:
Intel Wi-Fi 7 BE200
Bluetooth:
Yes
Bluetooth version:
5.4
Component for:
PC
Motherboard form factor:
Extended ATX
Motherboard chipset family:
Intel
Motherboard chipset:
Intel Z890
Audio output channels:
2.0 channels
Audio chip:
ESS ES9280AC + ESS ES9080
Product colour:
Black
PC health monitoring:
Fan, Temperature, Voltage, Water cooling
Windows operating systems supported:
Windows 11 x64
PCI Express x16 (Gen 4.x) slots:
1
PCI Express x16 (Gen 5.x) slots:
2
Number of M.2 (M) slots:
4
1st M.2 largest key size:
25110
1st M.2 highest PCI Express generation:
5.0
2nd M.2 largest key size:
25110
2nd M.2 highest PCI Express generation:
4.0
3rd M.2 largest key size:
22110
3rd M.2 highest PCI Express generation:
4.0
4th M.2 largest key size:
22110
4th M.2 highest PCI Express generation:
4.0
BIOS type:
UEFI AMI
BIOS memory size:
256 Mbit
ACPI version:
5.0
Clear CMOS jumper:
Yes
Clear CMOS button:
Yes
Desktop Management Interface (DMI) version:
2.7
System Management BIOS (SMBIOS) version:
2.7
Country of origin:
Taiwan
Products per shipping (inner) case:
1 pc(s)
Battery weight:
3 g
Lithium weight per battery:
0.07 g
Number of battery cells:
1
Battery technology:
Lithium-Manganese Dioxide (LiMnO2)
Battery type:
CR2032
Package width:
386 mm
Package depth:
370 mm
Package height:
140 mm
Package weight:
6.7 kg
Width:
304.8 mm
Depth:
305 mm
Height:
35 mm
Batteries included:
Yes
Antenna included:
Yes
Screws included:
Yes
Bundled software:
Norton® Internet Security (OEM version)
LAN bandwidth management software
Weight:
5.03 kg
Warranty period:
3 year(s)
